THLB Lithium Iron Phosphate Battery 2000 Cycles LFP Prismatic Solar Energy Battery
19.5kg Lithium Iron Phosphate Battery Pack 12V 200Ah LFP Prismatic Solar Energy Cell with rated cycle life of 2000 cycles
Main Kit Includes
| 1 x 12V200Ah LiFePO4 Battery Module |
1 x 4S-200A PCM |
1 x Plastic Battery Case |
2 x M8 Terminals |
Product Specification - Lithium Iron Phosphate Battery Pack 12V 150Ah for Camp Car
| Normal Voltage |
12.8V |
| Normal Capacity |
200Ah |
| Battery Energy |
2560Wh |
| Inner Resistance |
< 60mΩ |
| Battery Cycle Life |
2000 Times @100%DOD
6000 Times @80%DOD |
| Reference Battery Size |
(522±1)*(240±1)*(219±1) mm |
| Reference Battery Weight |
19.5±0.2 kg |
| Battery Encapsulation |
Plastic Case |
| Charge Voltage |
14.4V |
| Charge Mode |
CC/CV |
| Normal Charge Current |
<=50A |
| Normal Discharge Current |
75A |
| Max. Continuous Output Current |
150A |
| Max. Continuous Output Power |
2560W |
| Passive Protection Function |
Over charge protection; Over discharge protection; Over current protection, etc |
| Operation Temperature Range |
Charge: 0°C---45°C
Discharge: -20°C---60°C |
| Battery Storage Temperature |
-20°C---25°C |
| Individual Cell Approval |
CE / RoHS / UN38.3 / UL 1642 / IEC 62133 / CB / KC / BIS |
Our Company
Packing & Delivery
Frequently Asked Questions
Q1. Can I have few free samples for evaluation?
A: Yes, free samples are ok, but not covering shipping cost
Q2. What about the lead time?
A: Samples needs 3-5 days
B: Mass production time is approx 2-3 weeks
Q3. Do you have any MOQ limit for bulk order?
A: MOQ=100pcs
Q4. How do you ship the goods and how long does it take to arrive?
A: Samples and small quantity trial order: Courier shipping with door to door; normally 6-10 days
B: Big quantity bulk order: Air shipping or Sea shipping
Q5. How to proceed an order for Lithium ion cell?
A: Pls confirm the cell models that you are interested in
B: We send cell specifications and best quotation to you for reference
C: You confirm the quotation and inform quantity or issue PO, we will send PI accordingly
D: After deposit or full payment confirmed, production started
Q6. Is it OK to print my logo on lithium ion cell product?
A: Yes. OEM is welcomed
Q7: Do you offer guarantee for the products?
A: Yes, 3-5 Years Warranty
